Product Details:
|
| CPU: | RK3588 Octa-core CPU 8nm Process 4 X Cortex-A76 And 4 X Cortex-A55 | GPU: | ARM Mali G610 MP4 GPU |
|---|---|---|---|
| NPU: | 6Tops，int4/int8/int16/FP16 | MCU: | For Low Power Contro |
| RAM: | 4G/8GB/16G (optional) | Internal Memory: | 32GB/64GB/128GB/256GB(optional) |
| Operating System: | Android 12 | Dual Wired Network: | Support 10/100/1000M Ethernet*2 |
| WiFi: | IEEE 802.11a/b/g/n/ac | Mobile Network: | Supports Wireless 4G Network |
| Bluetooth: | Bluetooth 5.0 | TYPE_C: | USB Type_C*1 |
| DC Holder*1: | DC_12V Input 5.5*2.5mm Plug | ||
| High Light: | Rockchip Core Board,UHD Industrial Controlling Box Rockchip Board,Octa Core 8K Rockchip Board |
||
RK3588 super powerful, 8K HD output. It can be applied to smart cities, security, retail, robotics and industrial Internet, live broadcast machines, smart displays, edge computing, AloT solutions, smart large screens, high-end smart self-service terminals, and artificial intelligence in applications that require multiple cameras and displays. Intelligent terminal field etc.
1. RK3588 introduces a new generation totally hardware-based maximum 48-Megapixel ISP (image signal processor). It implements a lot of algorithm accelerators, such as HDR, 3A, LSC, 3DNR, 2DNR, sharpening, dehaze, fisheye correction, gamma correction and so on.
2. The build-in NPU supports INT4/INT8/INT16/FP16 hybrid operation and computing power is up to 6TOPs. In addition, with its strong compatibility, network models based on a series of frameworks such as TensorFlow/MXNet/PyTorch/Caffe can be easily converted.
3. RK3588 has high-performance quad channel external memory interface(LPDDR4/LPDDR4X/LPDDR5) capable of sustaining demanding memory bandwidths, also provides a complete set of peripheral interface to support very flexible applications.
FAQ for 8K controlling box:
Q: Are you trading company or manufacturer?
A: We are original manufacturer Of Embedded System Board
We can do OEM/ODM business.
Q: How long is your delivery time?
A: Group buying delivery time: 30-60 days; General delivery time: 20 days.
Q: What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.
Q: What is the warranty ?
A: The free warranty is one year from the day of Commissioning qualified.If there is any fault for our products within the free warranty period, we will repair it and change the fault assembly for free.
