Commercial touch screen 10.1inch Monitor Advertising Display Digital Signage capacitive tablet pc from Sunchip
| CPU |
Rockchip RK3288 Quad-Core Cortex-A17 Quad-Core GPU Mali-T764 |
| Frequency |
1.8 GHz |
| RAM |
LPDDR3 2G/4G optional |
| Built-in storage capacity |
EMMC 8GB/16G/32G/64G optional |
| Display interface |
LVDS interface (single, 6-bit dual, 8-bit dual). Support maximum resolution 1920x1080, support 7"-84" display |
| EDP port |
| Backlight Voltage |
Support 3.3V / 5V / 12V optional |
| Touch screen |
Provides I2C interface (can support multi-point resistance touch, multi-point capacitive touch).
Support USB multi-point infrared touch, multi-point sound wave touch, multi-point optical touch.
|
| Internet |
With RJ45 interface, support Ethernet. |
| With WIFI & BT module, support Wi-Fi 802.11b / g / n protocol. Support BT4.0 |
| Image rotation |
Support 0 degrees, 90 degrees, 180 degrees, 270 degrees manual / automatic rotation, support gravity sensing function |
|
Real Time Clock
|
Built-in real-time clock powered battery |
| Interface device |
Support MIPI interface camera, up to 500W pixels |
| 4 USB HOST, 1 USB OTG (support USB camera@500W USB printer, U disk, mouse, keyboard, standard USB peripherals) |
| 3 sets of serial ports. Support external serial device modules (NFC modules, printers, card readers, etc.) |
| TF card, maximum support 32GB |
| Class D amplifier: 3W*2 8 ohms, support microphone |
| HDMI 2.0 output |
| Audio |
MP3, WMA, WAV, APE, FLAC, AAC, OGG, M4A,3GPP format |
| Video |
Support H.264, VP8, RV, WMV, AVS, H.263, MPEG4 and other video formats 1080P decoding, YouTube and other online video, up to 1080P, HTML5 video playback, Flash10.1 play |
| Picture |
Support JPG, BMP, PNG and other picture formats to browse and support the rotation / slide show / picture zoom |
| Power Adapter |
Input:AC100-240V.50-60HZ, Output: DC12V 3A |
Certifications:
FAQ:
Q: Can you open the ROOT?
A: Yes.
Q: Can the OTG USB-A be USB-C?
A: Yes.
Q: Can I replace the booting LOGO by myself?
A: Yes, you can do it by ADB command, but we also can help you to add it to the system and finally generate a new firmware.
Q: Do you have any trade mark?
A: Yes, we do have trade marks in China, USA, Korea, Japan, EU.
Q: Do your product have reliability testing?
A: Yes. Every product will go with a serial strict testing after finished the development, and then
they will be produced to MP finally.
Q: Can I customize the MAC address and SN?
A: Yes. Clients can provide the MAC list to burn into the products, also can edit the SN by yourself and then provide the SN list to us.
Q: What is the product lifetime?
A: If the product is with lcd screen, usually it has 30K hours, 50K hours or other specification according to the screen datasheet. If it is not LCD product, 3~5 years.
Contact us:
Our main products:
-Android embedded motherboard
-4K/8K player box of media or industrial
-Different kinds of AIO lcd digital signage display machine
Let me know if any interest, will be happy to show you more details by return. thanks!
