Product Description:
RK3288 Motherboard LCD Controller Board forvending machine Digital Signage Advertising Player digital menu
Quad-core RK3288 Android Decoding Driver Integrated Board Specification
(Product model:AD-B02P-V1.1)
RK3288 Android integrated board adopts Rockchip RK3288 quad-core chip solution and supports Android 5.1 and above systems. Support the decoding of mainstream audio and video formats and pictures. Support EDP@4K, dual 8-bit LVDS interface 1920*1080, can drive 7" to 82" display screen. With HDMI interface, it supports 4K video playback. Abundant interfaces make the products more versatile and are widely used in intelligent control fields such as advertising machines, all-in-one machines, security, and industrial control. Due to its hardware platform and Android intelligent features, it can be used as an intelligent terminal platform when human-computer interaction or network device interaction is required.
Features:
- High performance. The RK3288 chip adopts the quad-core A17 solution, which is one of the most powerful quad-core chips on the market. The RK3288 motherboard solution using this chip has a qualitative leap in performance compared to the common single-core, dual-core, and quad-core solutions on the market. It can play various formats of high-definition video screens and can handle complex interactive operations.
-
- High stability. The RK3288 Android integrated board adds its own unique technology to the hardware and software to ensure the stability of the product, which can make the final product reach 7*24 hours unattended.
-
- High integration. RK3288 Android all-in-one board integrates functions such as Ethernet, wifi, Bluetooth, 4G, power amplifier, SD card, backlight power supply, etc., which greatly simplifies the design of the whole machine. The ultra-thin motherboard design can make the design of the whole machine more beautiful.
-
- High scalability. 5 USB ports and 3 serial ports, which can expand more peripheral devices.
Technical Parameters:
| ROM |
16GB/32GB EMMC |
| Power Supply |
DC 12V/2A |
| GPU |
Mali-T764 |
| Card Reader |
TF Card Reader |
| Network |
WiFi 802.11 B/g/n (2.4G/5G Wifi Optional) |
| RAM |
2GB/4GB |
| Display |
LVDS/EDP/MIPI/HD Out Optional |
| Camera |
Support USB Camera And MIPI Camera |
| CPU |
Rockchip RK3288 |
| Audio |
3.5mm Audio Jack |
This technical parameters table is suitable for Display PCB Board, Industrial Control Board, and Industrial Circuit Board.
| CPU |
Rockchip RK3288 Quad-core Cortex-A17 Quad-core GPU Mali-T764 |
| Main frequency |
1.8 GHz |
| Deposit |
LPDDR3 2G/4G Optional |
| Built-in storage capacity |
EMMC 8GB/16G/32G/64G etc. optional |
|
Display interface
|
LVDS interface (single-channel, 6-bit dual-channel, 8-bit dual-channel). Support maximum resolution 1920x1080, support 7"-82" display |
| EDP interface Maximum resolution 4K |
| Screen voltage |
Support 3.3V/5V/12V optional |
| Touch screen |
Support I2C touch screen, USB multi-point infrared touch frame, resistance, capacitive touch screen. |
|
The internet
|
With RJ45 interface, support 10/100M Ethernet. |
| Equipped with wifi&BT module, supporting Wi-Fi 802.11b/g/n protocol. Support BT4.0 |
| With 4G module, support 4G network |
| Image rotation |
Support 0 degree, 90 degree, 180 degree, 270 degree manual/auto rotation, support gravity sensor function (optional) |
| Real Time Clock |
External real-time clock power supply battery |
|
Interface device
|
Support MIPI camera |
| Support HDMI output |
| 5 USB HOST (support usb camera@500W usb printer, U disk, mouse, keyboard and standard usb peripherals) |
| 3 groups of serial ports (1 group of UART; 2 groups of standard UART or optional RS232). Support external serial devices (NFC module, printer, card reader, etc.) |
| 3 IO detection ports |
| TF card |
| D class large built-in speaker, 5W*2 8R |
| Support microphone |
| Audio |
MP3, WMA, WAV, APE, FLAC, AAC, OGG, M4A,3GPP format |
| Video |
Support H.264, MPEG2, VP6, VP8, MVC and other video formats 2160P@24FPS decoding. YouTube and other online videos, up to 4K, HTML5 video playback, Flash 10.1 playback |
| Image |
Support JPG, BMP, PNG and other image format browsing and support rotation/slide show/picture zoom function |
| Power Adapter |
Input:AC100-240V.50-60HZ, Output: DC12V 3A |
Applications:
Restaurant Digital Menu Boards, Retail shop - Digital Menu Boards, Retail Digital Signage,
Hotel Digital Signage, HealthCare Digital Signage,
Hotel catering, Advertising machine, Bank & Finance machine, School & Education product, Transportation product, Face recognition machine, electronic whiteboard, POS payment terminal, POS machine, Hospital self-service terminal, Commercial tablet, Smart evaluation machine,
Customization:
Available Customization that from Sunchip:
Regarding software:
1. Booting logo/animation
2. Model number of the Android System
3. Build number of the Android System
4. Pre-install APK
5. Delete APK
6. Set defaulted time zone
7. Set defaulted language
8. Virtual Keyboard (the current defaulted is English Keyboard)
9. Other requirements etc.
Regarding hardware: ODM layout
……More customization is waiting for your checking.
Support and Services:
The RK3288 Board product technical support and services include:
- Assistance with product setup, installation, and configuration
- Troubleshooting and resolution of technical issues
- Firmware and software updates
- Compatibility and integration support
- Product documentation and user manuals
- Warranty and repair services
1, More than 10 years of PCBA design and production experience.
2, A R&D team of more than 80 people, including hardware engineers (layout, debugging) and software engineers (drivers, kernels, testing, apk engineers).
ID Design engineer, Mechanical Design engineer, -> Support OEM/ODM.
3, Team of more than 160 people.
4, One-stop service: PCB design, prototype, production, PCBA SMT, testing, shell design, assembly, software customization, QC control, after-sales.
5, Got ISO9001 factory certification.
6, More than 3500 square meters of office and factory area
Packing and Shipping:
Product Packaging:
Shipping:
- Shipping Method: Standard Shipping
- Shipping Time: 4-5 business days
FAQ:
Q: Are you trading company or factory?
A: We are OED & ODM factory, and we have own hardware and software R&D team.
Q: How can I pay for samples and bulk order?
A: bank T/T,PayPal, Alibaba platform,West link,all of them are acceptable.
Q: What is the warranty time?
A: Defaulted 1-year. If need to add the warranty time, price will be increased.
Q: Do you have any discount?
A: Based on the different quantities, better prices if better quantities.
Q: How about the lead time?
A: Samples 1-7 days, MP 25-30 days.
Our main products:
-Android embedded motherboard
-4K/8K player box of media or industrial
-Different kinds of AIO lcd digital signage display machine
Let me know if any interest, will be happy to show you more details by return. thanks!
