Product Details:
Place of Origin: China
Brand Name: Sunchip, ADW
Certification: ISO 90001, ISO 27001 ,CE, ROHS
Model Number: AD-0140 BOX
Payment & Shipping Terms:
Minimum Order Quantity: 2pcs
Price: Negotiation
Packaging Details: 1pc/box
Delivery Time: 1-5days
Payment Terms: TT in advance
Supply Ability: 60000/Month

BT5.2 / WIFI / LAN/ 4G lte Supported Industrial Media Player RK3288 CPU With USB 2.0x2 digital signage box

Description
BT Support: Yes, BT5.0 CPU: RK3288
Accessories: Power Adpater, AC Cable, Antenna Color: Black
Material: Metal EMMC: 32GB/ 64GB/ 128GB/ 256GB, Optional
Name: Digital Signage Box, Media Player Box, Edge Computing Device POE: Support , Optional
Highlight:

RK3288 CPU Media Player Box

,

POE Support Media Player Box

,

BT5.2 Support Media Player

Product Description:


BT5.2 / WIFI / LAN/ 4G lte Supported Industrial Media Player RK3288 CPU With USB 2.0x2 digital signage box

Model: AD-0140 BOX (AD-B02P BOX)


Features:

SystemCPURK3288 quad-core Cortex-A17 @1.8G GPU Mali T764
RAM2GB/4GB (optional)
ROM16GB/32GB(optional)
OSAndroid 6-10 optional
NetworkWiFi802.11b/g/n (2.4G/5G optional)
Ethernet10M/100M Ethernet
Mobile NetworkSupport full Netcom 4G (optional)
BluetoothBluetooth 5.2
InteractiveInteractive modeSupport infrared remote control, support external expansion
InterfacesUSB interfaceSupport USB host*2
TYPE-Ctype-c interface*1
DCDC power 12V input
TF cardMaximum support 64GB
sim card slot4G mini PCIE port
HDMISupport HDMI output
Screen interfaceEDP screen interface_2K output / LVDS screen interface 1080P output (optional)
speaker8Ω*5W * 2(optional)
UARTUART3*1 (optional)
USB port expanderUSB port expandert*1 (optional)
RJ45Ethernet port
Headset3.5mm stereo headphone output




Sunchip-RK3288 High-Performance Platform
Sunchip-RK3288 is an all-in-one high-performance multi-core computing platform.
It features powerful graphics processing and video decoding ability,
and support for Android 7-10 OS.
It will become extra ordinary with your creativity.

Quad-Core High-Performance Board
Uses RK3288 quad-core Cortex-A17processor, supports 4K hardware decoding, has a rich expansion interface, as well as compatible with mainstream displays. It adopts the immersion gold process and has passed various pressure tests, which can be applied to the product directly.
RK3288 development board is an all-in-one high performance multi-core computing platform. Based on the Rockchip RK3288 SoC featuring an Arm Cortex-A17 (MP4) and Arm Mali-T760 (MP4), it features powerful graphics processing and video decoding ability, and support for Android OS.

High-performance Core Configuration
with RK3288 quad-core Cortex-A17 processor, frequency up to 1.8GHz, integrated quad-core Mali-T764 GPU. Its excellent performance makes products more possibilities.

Powerful Hardware Decoding Capability
It supports LVDS/EDP/ HD-MI display interfaces, 4K hardware decoding, dual-screen identical display/dual-screen differential display, and can drive the mainstream 5~100-inch display directly.

BT5.2 / WIFI / LAN/ 4G lte Supported Industrial Media Player RK3288 CPU With USB 2.0x2 digital signage box 0
BT5.2 / WIFI / LAN/ 4G lte Supported Industrial Media Player RK3288 CPU With USB 2.0x2 digital signage box 1

Support and Services:

Technical Support and Services for Media Player

Available Customization that from Sunchip:
Regarding software:
1. Booting logo/animation
2. Model number of the Android System
3. Build number of the Android System
4. Pre-install APK
5. Delete APK
6. Set defaulted time zone
7. Set defaulted language
8. Virtual Keyboard (the current defaulted is English Keyboard)
9. Other requirements etc.

Regarding hardware: ODM layout
……More customization is waiting for your checking.




FAQ
Q1: How did I trust your company?
A: SUNCHIP a software and hardware solution provider who has 12-years old from Shenzhen, China. We have a good reputation in this industrial area when you check it with almost all of Shenzhen industrial suppliers.
Q2: How long will you ship out the goods after I place the order on you?
A: If in-stock, usually, it’ll take 1-3 days to prepare and ship out. Before shipping, we should do aging testing and normal function testing, QC inspection, then, ship out. If out of stock and need to re-produce the goods, it will take different lead time.
For android board, android media player box, android LCD digital signage machine, will take about 15-30 days, depending the product quantities and types.
Q3: After i get the products what if my products broken, what kind of service you support?
A: First contact us, tell us about the problem, our engineer will help to handle; secondly, you can send back the products to us, we will fix it. we support 12 months warranty, any problem catches me online, we can give you good solution way. we want to do long term business with you not just for 1 day 1 time.
Q4. Shipping solution?
We support Express, such as, DHL/FedEx/UPS/TNT etc., also support sea shipping, air shipping and railway shipping, depends on the customer’s request.
