4G PCIE RK3399 Media Player With WIFI BT Gigabit Ethernet For Digital Menu Boards

4G PCIE RK3399 Media Player With WIFI BT Gigabit Ethernet For Digital Menu Boards
4G PCIE RK3399 Media Player With WIFI BT Gigabit Ethernet For Digital Menu Boards
4G PCIE RK3399 Media Player With WIFI BT Gigabit Ethernet For Digital Menu Boards 4G PCIE RK3399 Media Player With WIFI BT Gigabit Ethernet For Digital Menu Boards 4G PCIE RK3399 Media Player With WIFI BT Gigabit Ethernet For Digital Menu Boards 4G PCIE RK3399 Media Player With WIFI BT Gigabit Ethernet For Digital Menu Boards 4G PCIE RK3399 Media Player With WIFI BT Gigabit Ethernet For Digital Menu Boards 4G PCIE RK3399 Media Player With WIFI BT Gigabit Ethernet For Digital Menu Boards

Large Image :  4G PCIE RK3399 Media Player With WIFI BT Gigabit Ethernet For Digital Menu Boards

Product Details:
Place of Origin: China
Brand Name: ADW, SUNCHIP
Certification: CE, FCC, Rohs
Model Number: AD-0150 box (AD-B03 BOX)
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: Negotiable
Packaging Details: 1PCS/BOX, 5PCS/Carton
Delivery Time: 30 days
Payment Terms: T/T, Western Union, PayPal
Supply Ability: 10000 pcs per month

4G PCIE RK3399 Media Player With WIFI BT Gigabit Ethernet For Digital Menu Boards

Description
CPU: RK3399, Media Player Ram: 4GB
Rom: 16GB/32GB/64GB Optional Material: Metal
OS: Android 7.1, 9.0, 10.0 Etc. WIFI: 802.11 A/b/g/n/ac
Charger Type: US/UK/EU Optional Resolution: 2k / 4K Optional
Cloud Storage Support: Yes Compatibility: MP3, AAC, WMA, FLAC, OGG, AVI, WMV, MOV, Etc.
Customizable Interface: Yes Equalizer: Yes
Platform: Android Remote Control: Yes
Audio Quality: High Name: Media Player
Playlist Support: Yes
High Light:

RK3399 Media Player

,

4G PCIE Media Player

,

Digital Menu RK3399 Media Player

4K RK3399 MEDIA PLAYER

AD-0150
RK3399 Hexa-Core Cortex-A72 & Cortex-A53
4K HD Out
WIFI & Bluetooth Support
4G PCIE function optional

Super Development Board 4K RK3399 A72 A53 Indoor Advertising Digital Signage Media Player Box For Digital Menu Boards

RK3399 super developed board is specially designed for Rockchip RK3399 solution. It has features of compact structure, full function interfaces, flexible to use, suitable for software lovers to study developing of Android system and debugging software and hardware of Rockchip RK3399 solution. It also suits for corporation assessing property parameters of Rockchip RK3399 applied in tablet, home smart HD network player, vehicle multimedia controller, security monitoring network and various carry-on multimedia entertainment products, at the same time providing with products software and hardware development, debugging platform or product design reference.

As the enterprise level digital signage player powered by AD-0150, it can easily turn any ordinary TV, monitor or screen into highly versatile digital signage display. Featuring 4K display, reliable network and RS232 interfaces, it is your perfect choice for any digital signage project large or small, complex or simple.



With industrial durability and outstanding performance,AD-0150 can be confidently deployed to digital signage application fields like retail, restaurant, transportation, corporation, public service and more.



Main Features:

CPU Rockchip RK3399 dual core Cortex-A72+ quad core Cortex-A53 CPU,1.8GHZ +1.4Ghz
RAM LPDDR4 4G
ROM EMMC 8GB/16GB/32GB/64GB optional (default 16GB)
Network With RJ45 interface,Support 10/100/1000M Ethernet
Support 4G PCIE interface
With WIFI & BT module, support Wi-Fi 802.11a / b / g / n / ac protocol. Support BT 5.2
Real Time Clock Built-in real-time clock powered battery
Interfaces 1*USB2.0,1*USB3.0,1*TF card Slot,1*SIM Slot,1*HDMI OUT,1*Ethernet,1*Earphone,1*Type-C,1*Power-in
Video Supports H.264, MPEG2, VP6, VP8, MVC and other video formats. Online videos such as YouTube, up to 4K, HTML5 video playback, Flash 10.1 playback



3399 is a hexa-core single-board computer based on Rockchip RK3399 processor with two Cortex A72 cores clocked at up to 1.8GHz, and four Cortex A53 cores teamed with a Mali-T860MP4 GPU, featuring 3G/4G and WiFi/BT module, supporting 4K H.265 video decoding up to 60 fps, HDMI output, USB Type-C, Gigabit Ethernet, Android 7-10 operating system.





Application:



Media Player Boxes are currently widely used in large shopping malls, specialty stores, franchise stores, subways, airports, bookstores, parks, exhibition halls, stadiums, conference centers and other places.



Model No.: AD-0150 Box Model Name: Android Media player box
Size: 170*96*20MM



Hardware Spec:
Operation System Android 7-10
Language Chinese,English...Multi-Language support
CPU RK3399
GPU ARM Mali-T864 GPU
SDRAM  4GB
Flash 16GB/32GB/64GB (EMMC) Optional
Network RJ45 10/100/1000M Ethernet
WIFI Module AP6256
Power Supply DC 12V/3A 5.5mm DC-in
Camera 200W /500W , USB type
Interface:
  support maximum 4Kx2K@30fps max resolution
output
USB Port 2*USB Host
AUDIO Out 1*3.5mm Headphone Jack
Network 1*RJ45 10/100/1000M Ethernet
Power Supply 1*DC Jack 12V/3A 5.5mm DC-in
TF card Interface TF Card, up to 32GB
External antenna 2.4G/ 5G 3dbi optional
Media Parameter
Audio Container Supports MP3,WMA,WAV, APE, FLAC, AAC, OGG,M4A,3GPP

Video Decoder Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *. *.mp4, and *.jpg file formats
Video Encoder H.264/MVC/VP8 encoder by 1080p@30fps
Resolution Maximum resolution is 4Kx2K
H.265 Data Rate H.265 decoder by 2160p@60fps
Software Extension APK install
Infrared remote control  IR remote
IM Software Support Skype/QQ/MSN/GTALK (Depends on APK)
Offic Software WORD/EXCEL/PDF(Depends on APK install)
Others Parameters:
Operationg Temperature 0~70℃
Storage Temperature -10~70℃
Humidity environment 5%-90%(No condensation)
Package
Dimension 258*147*67MM
Net weight 0.534kg
Gift Box Size 195*153*70mm
Packing accessories
1, AC cable
2, 12V/3A adapter
3, Remote control
4, External antenna

4G PCIE RK3399 Media Player With WIFI BT Gigabit Ethernet For Digital Menu Boards 04G PCIE RK3399 Media Player With WIFI BT Gigabit Ethernet For Digital Menu Boards 1

4G PCIE RK3399 Media Player With WIFI BT Gigabit Ethernet For Digital Menu Boards 24G PCIE RK3399 Media Player With WIFI BT Gigabit Ethernet For Digital Menu Boards 3



4G PCIE RK3399 Media Player With WIFI BT Gigabit Ethernet For Digital Menu Boards 4





About Sunchip :



SUNCHIP is an OEM / ODM factory, customizing products to tailor your needs is our strength and mission, over 130 employees’ team that including over 70 research and development engineers, who can provide services and solutions in electronic Android mainboard design for digital signage industries and domains as it is becoming a critical function in the product development life cycle, diverse categories of embedded systems such as industrial automation, consumer electronics, embedded digital signage devices and exhibition display screen.





We focus on Rockchip chipsets solution and in-depth development, also deep customization of Android OS; Specialized on LCD Digital Signage & Android ARM Board.





Sunchip is a national high-tech enterprise with various patents. Our factory runs under the ISO 9001 & ISO 14001 certification. Our products fully completely with CE, RoHS and FCC certifications.



Sunchip has become the ODM / OEM partner of a number of world-class companies. Our products have been exported to over eighty worldwide countries.We do the best we can consistently to provide excellent quality products and one-stop services for all customers.

We are looking forward to cooperating, developing and growing with you sincerely.





4G PCIE RK3399 Media Player With WIFI BT Gigabit Ethernet For Digital Menu Boards 5





We mainly manufacture



1, Android industrial Embedded board: RK3588, RK3566, RK3568, RK3288, RK3399,

RK3328, RKPX30, RK3188, RK3128 etc.

2, 【4K】Android media player box for digital signage advertising: RK3399, RK3288, RK3328.

3, 【8K】Android Player Box for Industrial-Control Application: RK3588.

4, Stretched lcd Display signage, support ODM.

5, Open frame LCD display signage: 8inch, 10.1inch, 13.3inch, 15.6inch, 21.5inch etc.

6, SKD Kit: Android board + LCD panel with touch or not:

7inch, 8inch, 10.1inch, 13.3inch, 15.6inch.

7, Other types of Wall Mounted / Floor Standing / Desktop LCD digital signage.

8, Embedded touch desk: such as 32inch.

9, Face recognition temperature detection terminal machine: such as 8inch.



[you can also tell us your requirements, so that we advise you a matched solution]
