Product Details:
|
| Material: | Metal | Color: | Black/Google Gray |
|---|---|---|---|
| CPU: | RK3328 Quad-core Cortex-A53, Clocked Up To 1.5GHz | Operating System: | Android 7.0 |
| Interactive Mode: | Support Infrared Remote Control, Support External Expansion | HD: | Support HD Output Support 4K 60FPS Frame Rate |
| High Light: | USB Plug Media Player Box,Plug And Play Media Player Box,Media Player Box For Digital Signage |
||
USB Plug And Play HD Media Player Box For Digital Signage And Kiosk
Model: AD-B01 Media player Box
1. System CPU RK3328 quad-core Cortex-A53, clocked up to 1.5GHz GPU Mali-450MP2
2. RAM 1GB/2GB (optional)
3. Internal memory 8GB/16GB/32GB(optional)
4. Operation system Android 7.1
5. Network WiFi 802.11 a/b/g/n_2.4G (802.11 a/b/g/n/ac_5G optional)
6. Mobile network Support full Netcom 4G (optional)
7. Buletooth Bluetooth 4.0
8. Ethernet 10M/100M Ethernet
9. Interactive Interactive mode Support infrared remote control, support external expansion
10. Interface USB interface Support USB 2.0(1) & USB 3.0(1) TYPE C interface TYPE C interface
11. DC DC power 12V input
12. TF card Maximum support 64GB
13. HD Support HD output Support 4K 60FPS frame rate
14. RJ45 Ethernet port
15. Headset 3.5mm stereo headphone output
16. Fiber Support fiber output
17. Speaker 8Ω*5W * 2(optional)
18. USB port expander Support USB port expandert*1(optional)
19. LED light Support USB port expandert*1(optional)
20. UART Support UART2*1(optional)
21. Media play Video format MPEG-1,MPEG-2,MPEG-4,H.263,H.264,H.265,VC1,VP8,RV etc.,support up to 3840x2160
22. Audio format MP3,WMA,WAV, APE, FLAC, AAC, OGG,M4A,3GPP etc.
23. Text processing EPUB, WORD, EXCEL, POWERPOINT, PDF,
24. E-book PDF,TXT,CHM,DOC,EXCEL,EPUB,RTF,FB2
25. Photo JPG,BMP,PNG
26. APK install APK installer
27. Root permission Original ecological Android system, open root permissions, customizable development
28. Remote control Real-time remote monitoring, system crash self recovery, 7*24 hours unattended
29. OTA upgrade Support OTA remote upgrades
30. Accessories Adapter Adapter,12V/2A
31. User manual
| System | CPU | RK3328 quad-core Cortex-A53, clocked up to 1.5GHz GPU Mali-450MP2 | ||||||||||||
| RAM | 1GB/2GB (optional) | |||||||||||||
| Memory | 8GB/16GB/32GB(optional) | |||||||||||||
| Operating system | Android 6.0 | |||||||||||||
| Network | WiFi | 802.11 a/b/g/n_2.4G (802.11 a/b/g/n/ac_5G optional) | ||||||||||||
| Mobile network | Support 3G,4G(optional) | |||||||||||||
| Bluetooth | Bluetooth 4.0 | |||||||||||||
| Ethernet | 10M/100M Ethernet | |||||||||||||
| Interactive mode | Interactive mode | Support infrared remote control, support external expansion | ||||||||||||
| Interface | USB interface*2 | Support USB 2.0(1) & USB 3.0(1) | ||||||||||||
| TYPE C interface | TYPE C interface | |||||||||||||
| DC | DC power 12V input | |||||||||||||
| TF card | Maximum support 64GB | |||||||||||||
| HD | Support HD output Support 4K 60FPS frame rate | |||||||||||||
| RJ45 | Ethernet port | |||||||||||||
| Headset | 3.5mm stereo headphone output | |||||||||||||
| Fiber output | Support fiber output | |||||||||||||
| Speaker output | Support 8 ohm 5W speaker dual channel output interface | |||||||||||||
| LED light | Support extended power LED indicator (optional) | |||||||||||||
| Serial port expansion | Support serial port expansion interface *5 (optional) | |||||||||||||
| Support CAN interface | Support CAN interface expansion interface (optional) | |||||||||||||
| Media playback | Video format | MPEG-1,MPEG-2,MPEG-4,H.264,H.265,VC1,VP8,4K VP9,4K 10bits H265/H264,HDR10,HLG HDR,Maximum support 3840x2160 | ||||||||||||
| Audio format | MP3,WMA,WAV, APE, FLAC, OGG,M4A,3GPP format | |||||||||||||
| Text processing | EPUB, WORD, EXCEL, POWERPOINT, PDF, TXT | |||||||||||||
| Ebook | PDF,TXT,CHM,DOC,EXCEL,EPUB,RTF,FB2 | |||||||||||||
| Image Format | JPG,BMP,PNG | |||||||||||||
| System Management | APK install | APK installer | ||||||||||||
| Root permission | Original Android system, open root permissions, product customization development | |||||||||||||
| Remote control | Real-time remote monitoring, system crash self-recovery, 7*24 hours unattended | |||||||||||||
| OTA upgrade | Support OTA remote upgrade | |||||||||||||
| Accessory | Adapter | Power adapter 12V/2A | ||||||||||||
| User's Guide | Standard | |||||||||||||
| Warranty Card | Standard | |||||||||||||
| Product size, unit:mm | ||||||||||||||
| Product size | colour box size | Carton pcs/CTN | ||||||||||||
| L | W | H | L | W | H | L | W | H | ||||||
| 195 | 100 | 20 | ||||||||||||
| Net(kg) | Net(kg) | Net | ||||||||||||
| G.W | ||||||||||||||
