Product Details:
|
| CPU: | RK3188 Or Rockchip 3288 | Ram: | 1GB Or 2GB |
|---|---|---|---|
| Rom: | 8GB Or 16GB | Resolution: | 1920*1080P |
| Material: | Metal | OS: | Android 4.4 Or 5.1 |
| WIFI: | 802.11 B/g/n | 4G LTE: | Optional |
| High Light: | Wall Mount Vertical Digital Signage Display,Android WiFi Vertical Digital Signage Display |
||
32 Inch Wall Mount Vertical Digital Signage Display, Android WiFi,1920x1080,178°,500cd/m2,5ms,AC110V-240V
Vertical Digital Signage Display main features:
1. Place of Origin: Guangdong, China (Mainland)
2. Type: TFT
3. Application: Indoor
4. Panel Size: 32 Inch
5. Max Resolution: 1920x1080
6. Viewing Angle: 178x178
8. Pixel Pitch: 0.76125x0.76125mm Color: 8Bit,16.7M
9. Contrast Ratio: 4000:1
10. Brightness: 500cd/m2
11. Response Time: 5ms
12. Input Voltage: AC110V-240V,50/60HZ
13. surface: anti-glare
14. panel backlight: CCFL
15. control method: RS232 control
16. consummtion: 180W
17. signal support: DVI//VGA/AV/YPBPR
18. Color system: PAL/NTSC/SECAM
19. Operation System: Android
20. Menu language: Multiple languages
Motherboard specs:
| CPU | Rockchip RK3188 Quad core Cortex-A9 GPU Mail-400 @ 533MHz |
| Frequency | 1.6 GHz |
| RAM | DDR3 2G Optional |
| Rom | NAND FLASH 8GB |
| DIF | LVDS interface(Single, 6-way, 8-way dual).Support maximum resolution 1920x1080, support 7 "-82" display. |
| Onboard backlight | 12V |
| LCD voltage | 3.3V/5V/12V optional |
| Touch screen |
Provide I2C interface (can support multi-point resistance touch, multi-point capacitive touch). Support USB multi-point infrared touch, multi-point sound saw touch, multi-point optical touch. |
| Network | Have RJ45 interface,support Ethernet. |
| Have wifi&BT module,support Wi-Fi 802.11b/g/nprotocol.Support BT3.0/BT4.0 | |
| Image rotation | Support 0 degree,90 degree,180 degree,270 degrees manual / automatic rotation, support gravity sensing function. |
| Real Time Clock | Built-in real-time clock powered battery |
| Interface device | Support DVP interface camera, the maximum support 500W pixels |
| Support USB camera | |
| 3 USB HOST (1 motherboard, 2 small board), 1 USB OTG | |
| 1 group serial port. Support external serial device module (3G module, NFC module, printer, card reader, etc.) | |
| 1 group of I2C ports | |
| SD card, maximum support 32GB | |
| D class large built-in speaker, 8 oh / 3W | |
| Support for microphones | |
| Audio | MP3,WMA,WAV, APE, FLAC, AAC, OGG,M4A,3GPP |
| Video | Support H.264,VP8,RV,WMV,AVS,H.263,MPEG4 video formats such as 1080P decoding, YouTube and other online video, up to 1080P, HTML5 video playback, Flash 10.1 play |
| Picture | Support JPG, BMP, PNG and other picture formats to browse and support the rotation / slide show / picture zoom |
| Power Adapter | Input AC100-240V.50-60HZ, output:DC12V 3A |
